| A. |
SECTIONS CONNECTION TYPE |
| |
WITH SEMI-AUTOMATIC FEEDING/FORMING SYSTEM
Material: welded mild steel, welded stainless steel, extruded alloyed alum. Pipe |
| |
 |
| Model # |
Base-Section(O.D.) |
Mid-Section(O.D.) |
Top-Section |
| TP-5150B |
Max 140mm(5.5") |
114mm |
89mm |
| TP-6200B |
Max 165mm(6.5") |
140,114mm |
89mm |
| TP-8250B |
Max 210mm(8.5") |
190,165,140,114mm |
89mm |
|
 |
|
| |
| B. |
ONE PIECE TYPE |
| |
FULLY AUTOmatic FEEDING/FORMING SYSTEM
With NC CONTROL BY ONE TIME FORMING
Material welded mild steel, welded stainless steel, extruded alloyed alum. pipe
| Model # |
Base O.D. |
End-Tip |
Height |
Max. Thick |
| STP-6100 |
140mm |
80-100mm |
6-12M |
3.8mm |
| STP-7100 |
165mm |
100-120mm |
6-12M |
4.8mm |
| STP-8100 |
210mm |
120-140mm |
6-12M |
5.0mm |
|
|
 |
|
| C. |
AUTO BENDING MACHINE FOR TOP SECTION |
| |
HYDRAULIC DOUBLE WAY BENDING WITH PLC CONTROL |
| |
| Model # |
Max. O.D. x Raduis |
Motor |
| TPB-180 |
Ø180~120 x R.750mm |
50HP |
| TPB-140 |
Ø140~89 x R600mm |
30HP |
|
|
| |
|
| * Customer design is available! |
